781212302402

Switch mode power supplies Power consumption: 28.2 VA. Modular version: yes Suitable for safety functions: no Width in number of modular spacings: 1 Voltage type of supply voltage: AC/DC Power output: 12 W. Output voltage stabilized: yes Type of electric connection: Screw connection Rail mounting possible: yes Wall mounting possible: no Stabilized: yes 1st secondary output voltage: 24 V. Secondary voltage adjustable: no Rated supply voltage at AC 50 Hz: from 110 to 240 V. Rated supply voltage at DC: 220 V. Short-circuit-proof: yes Performance level according to EN ISO 13849-1: None Max. output current 1: 0.63 A. Nominal value output voltage 1: 24 V. Nominal value output current 1: 0.5 A. SIL according to IEC 61508: None Protection category: IP20

Dimensions (m): L 0.069 x W 0.025 x D 0.095
