782512302400

Switch mode power supplies Power consumption: 56.4 VA. Modular version: yes Suitable for safety functions: no Width in number of modular spacings: 2 Voltage type of supply voltage: AC/DC Power output: 25 W. Output voltage stabilized: no Type of electric connection: Screw connection Rail mounting possible: yes Wall mounting possible: no Stabilized: yes 1st secondary output voltage: 24 V. Secondary voltage adjustable: no Rated supply voltage at AC 50 Hz: from 110 to 240 V. Rated supply voltage at DC: 220 V. Short-circuit-proof: yes Performance level according to EN ISO 13849-1: None Max. output current 1: 1 A. Nominal value output voltage 1: 24 V. Nominal value output current 1: 0.75 A. SIL according to IEC 61508: None Protection category: IP20

Dimensions (m): L 0.065 x W 0.055 x D 0.105
