782A12302402

Switch mode power supplies Power consumption: 361 VA. Modular version: yes Suitable for safety functions: no Voltage type of supply voltage: AC Power output: 240 W. Output voltage stabilized: yes Type of electric connection: Screw connection Rail mounting possible: yes Wall mounting possible: no Stabilized: yes 1st secondary output voltage: from 24 to 28 V. Secondary voltage adjustable: no Rated supply voltage at AC 50 Hz: 230 V. Short-circuit-proof: yes Performance level according to EN ISO 13849-1: None Max. output current 1: 10 A. Nominal value output voltage 1: 24 V. Nominal value output current 1: 9 A. SIL according to IEC 61508: None Protection category: IP20

Dimensions (m): L 0.160 x W 0.050 x D 0.152
