7E1682300010

Energy meters Model: Direct measurement Suitable for: Purchase Type of indication: Analogue Frequency: 50 Hz. Max. current (Imax): 65 A. Width in number of modular spacings: 2 Number of positions total (counter): 7 Type of meter: Electromechanical Protection category: IP50 Type of interface: None Energy type: Effective power Tariff type: One-tariff Tariff control: External Escapement mechanism: yes Calibrated: yes Approval: Measuring Instruments Directive Pulse output: Electrical Pulse type: S0 Pulse rate: 1000 Imp/kWh (kvarh). Accuracy class: B Pole type: Single phase With lock code: no Nominal voltage (Un) N-L: from 184 to 264 V. Nominal current (In): 10 A. Accessories: Tamper-proof cover with lead seal facility availabes Note: Montaggio su barra 35 mm (EN 60715)

Dimensions (m): L 0.042 x W 0.095 x D 0.080
