7E8684000112

Energy meters Model: Measurement transformer Suitable for: Purchase/supply Type of indication: Digital Frequency: from 50 to 60 Hz. Max. current (Imax): 6 A. Width in number of modular spacings: 4 Number of positions total (counter): 8 Type of meter: Electronic Protection category: IP50 Type of interface: Other Energy type: Effective power and blind power Tariff type: Two-tariff Tariff control: External Escapement mechanism: yes Calibrated: yes Approval: Measuring Instruments Directive Pulse output: Electrical Pulse type: S0 Pulse rate: 1000 Imp/kWh (kvarh). Accuracy class: B Pole type: Three conductor/four conductor With lock code: no Nominal voltage (Un) N-L: from 184 to 276 V. Nominal current (In): 1 A. Accessories: Tamper-proof cover with lead seal facility availabes Note: Montaggio su barra 35 mm (EN 60715)

Dimensions (m): L 0.085 x W 0.115 x D 0.085
